1. What is an AIO flight controller?

An AIO flight controller combines the FC and ESC into one compact board, reducing weight and simplifying installation for FPV drone builds.

2. AIO flight controller vs Stack: Which one should I choose?

An AIO board is lighter and easier to install, making it ideal for Micro FPV, Toothpick, and Cinewhoop builds. A stack offers higher power capacity and is better for demanding 5-inch builds.

3. What is a 1S AIO flight controller used for?

A1S AIO flight controller is designed for Tiny Whoop and lightweight Micro FPV drones that use 1S batteries.

4. What is the difference between 1S and 2S AIO flight controllers?

A 1S AIO is optimized for lightweight builds, while a 2S AIO flight controller provides more power for faster Micro FPV and Toothpick drones.

5. How do I choose an AIO ESC flight controller?

Choose based on your drone size, battery voltage, and motor power. Smaller builds need lightweight AIO boards, while larger builds require higher-current ESCs.

6. What are 16x16, 20x20, and 25x25 AIO flight controllers?

These numbers refer to the board mounting size.16x16 AIO flight controllers fit compact builds, 20x20 AIOs are common for Micro FPV, and 25x25 AIOs suit larger lightweight builds.

7. Can I use an AIO flight controller for Cinewhoop?

Yes. Higher-current AIO boards are suitable for Cinewhoop builds, especially those using 3S-6S batteries and HD FPV systems.

8. Can AIO flight controllers work with HD FPV systems?

Some AIO flight controllers support HD FPV systems through dedicated connectors or UART connections. Check the product specifications before building.

9. What motors and batteries work with an AIO flight controller?

Match your setup with the AIO power rating. Micro builds usually use small motors and 1S-2S batteries, while 3-5-inch builds need higher-current AIO boards.

10. Are AIO flight controllers good for beginners?

Yes. AIO flight controllers reduce wiring and simplify installation, making them a popular choice for first FPV builds.

FPV AIO Flight Controller

FPV AIO flight controllers integrate FC and ESC into one compact board, providing lightweight solutions for 1S micro drones, toothpicks, cinewhoops, and freestyle builds.

Tiny Whoop & Micro FPV AIOs

For 1S micro drones, Tiny Whoops, and beginner FPV builds.

darwinfpv 1 3s f411 15a bluejay aio right

100+ Sold

-14%

Happymodel CrazyF405 HD ELRS 12A 1-2S AIO Flight Controller Built-in ELRS 2.4GHz Receiver and BLHELI_S 4-in-1 ESC

$66.99

Cinewhoop & HD FPV AIOs

For high-power Cinewhoops and HD FPV builds requiring more performance.

GOKU GN 745 45A AIO 32bit (MPU6000 ) V3 Picture

-20% OFF

Flywoo GOKU GN 745 45A AIO 32bit V3 Plug&Play O4 / O4 Pro

$102.99

t hobby f7 35a 45a aio for cinewhoop toothpick

-22% OFF

T-HOBBY F7 35A/45A Aio For Cinewhoop Toothpick

$99.90

geprc gep f722 45a aio v2 flight controller 2 6s

-10% OFF

GEPRC GEP F722 45A AIO V2 Flight Controller 2-6S | 45A ESC | Cinewhoop & 3-5” Freestyle FPV Drone Builds

$116.63

-27% OFF

JHEMCU GHF745 HD AIO 40A F7 OSD Flight Controller and Built-In AM32 3-6S 4IN1 ESC - 25x25mm

$79.99

-20% OFF

JHEMCU GHF405 F4 HD 2-6S AIO Flight Controller 40A 4in1 ESC FPV

$62.90

-15% OFF

Aikon F7 AIO Board - F7 FC + 60A 3-6S BLHeli_S ESC

$109.99

-19% OFF

iFlight BLITZ Whoop F7 Lightweight 55A AIO ICM42688

$125.99

Toothpick & Lightweight Freestyle AIOs

For 2-4 inch toothpick and lightweight freestyle FPV drones.

-22% OFF

T-HOBBY F7 35A/45A Aio For Cinewhoop Toothpick

$99.90

-8% OFF

Lumenier LUX HD Solderless AIO - G4 FC + 35A AM32 3-6S ESC

$133.99

-9% OFF

GEPRC GEP-F722-35A 2-6S AIO for Cinewhoop & Toothpick FPV Build for Pilots

$104.99

Choose the Right FPV AIO

Match Your Drone Size

Tiny Whoop, Toothpick, or 2-4 Inch Builds

Check Battery Voltage

1S, 2S, or 3S-6S Power Setup

Match ESC Current

Select 5A-60A Based on Motor Power

Verify System Support

Check Firmware, Receiver, Video System & Ports

Find the Right FPV AIOs for Your Build

Drone Size	Recommended AIO	Motor Setup	Battery Setup	Best For
Tiny Whoop (65-85mm)	1S AIO / 5A-10A ESC	0702/0802 / 1002 motors	1S 300-550mAh	Indoor flying, beginner FPV, lightweight builds
1.5-2 Inch Micro FPV	1S-2S AIO / 10A-20A ESC	1102 / 1202 / 1204 motors	1S 450-850mAh 2S 300-650mAh	Micro freestyle and racing whoops
2.5-3 Inch Toothpick	2S-4S AIO / 15A-35A ESC	1404 / 1804 / 2004 motors	2S-4S 450-850mAh	Lightweight freestyle and outdoor flying
3-4 Inch Cinewhoop	3S-6S AIO / 35A-45A ESC	1404 / 1606 / 1804 motors	4S 850-1500mAh 6S 850-1300mAh	HD FPV, cinematic flying, compact builds
5 Inch FPV	High Current AIO / 45A-60A+ ESC	2203 / 2205 / 2207 motors	4S-6S 1100-1500mAh	Freestyle, racing, high-power builds

ALL FPV AIOs

AIO

Price

$

FPV AIOs Combo Kits

Ultra-light Tiny Whoop setup designed for indoor flying and beginner practice, offering easy control, low noise, and a fun entry-level FPV experience.

New HappyModel X12 AIO 5-IN-1 Flight controller - F4 FC + 12A ESC

T-HOBBY M0802ⅡKV27000 Microwhoop Motor For Indoor FPV Drone

MEPS SZ1218 Tinywhoop Propeller for FPV Micro Drones Lightweight

New BETAFPV BT2.0 450mAh 1S 30C Battery (4PCS) for Whoop Drone

Lightweight long-range 3" setup with efficient F1404 motors and 3S–6S battery support, ideal for smooth cruising, freestyle practice, and outdoor exploration.
