Buying Guide: Flywoo NIN 1404 V2 Ultralight FPV Motor
Why Choose NIN 1404 V2?
Choosing a motor for a lightweight FPV build is not only about maximum power. The best motor should provide the right balance between torque, efficiency, weight, and control.
For 3-inch Toothpick and lightweight freestyle drones, smaller motors can save weight but often lack torque when using larger props or carrying bigger batteries. Larger motors provide more power but increase weight and reduce the advantages of a lightweight build.
The NIN 1404 V2 sits in the ideal middle ground:
● More torque than 1204/1304 motors
Better efficiency than larger freestyle motors
● Enough power for aggressive 3-inch flying
● Lightweight enough for sub-250g builds
It is a great choice for pilots who want a micro FPV drone that feels powerful without becoming heavy or inefficient.
Finding Your Ideal Setup
| Flying Style | Recommended Setup | Characteristics |
|---|
| Micro Long Range | 2750KV + efficient props | Lower current draw, smoother cruising, longer flight time |
| Everyday 3" FPV | 3750KV + 3S/4S battery | Best balance of speed, control, and efficiency |
| Lightweight Freestyle | 4850KV + 3" low‑pitch props | Faster response, stronger acceleration, more aggressive flying |
The NIN 1404 V2 works especially well with lightweight 3‑inch builds where maintaining low weight is important. It provides the torque needed for larger 3‑inch props without adding the weight penalty of larger motors.
Recommended Components
● Frame: 3" Toothpick / Lightweight Freestyle / Micro LR Frame
● Battery: 3S‑4S LiPo depending on KV selection
● Propeller: Lightweight 3" low or medium pitch props
● ESC: 12A‑20A Micro ESC or AIO Flight Controller
● Best Match: Lightweight build under 250g
For long‑range builds, lower KV versions pair well with efficient propellers and larger capacity batteries. For freestyle builds, keeping the frame and battery weight low helps the motor deliver the best response.
MEPSKING Real Flight Experience
We tested the NIN 1404 V2 4850KV on a lightweight 3-inch Toothpick build. The result was impressive — although the KV was lower than some traditional high-KV 1404 motors, the actual flight performance remained extremely strong.
The motor delivered:
● Fast acceleration close to larger 5-inch style performance.
● Smooth throttle control during normal cruising.
● Enough power that most flying could be done at only 20–40% throttle.
During aggressive full-throttle testing, the limitation was not the motor but the battery. A small 3S battery could not continuously provide the current required by this powerful setup.
The test also showed that propeller selection is critical. Lower-pitch 3-inch props provided a better balance between speed, control, and battery efficiency, while aggressive high-pitch props consumed too much power.
For pilots choosing the 4850KV version, a lightweight build and efficient prop combination will provide the best experience.
Motor Comparison
Compare the NIN 1404 V2 with other popular 1404 motors:
| Feature | NIN 1404 V2 | T‑HOBBY F1404 Motors | T‑HOBBY F30 1404 Motor | RCINPOWER GTS V3 1404 Plus Motor |
|---|
| Main Focus | Balanced performance & versatility | Long‑range efficiency | Racing performance | Premium freestyle/racing |
| Best Application | 3" Toothpick, freestyle, micro LR | 3"‑4" long‑range builds | 3" racing builds | High‑performance freestyle builds |
| Flying Style | Smooth torque with strong acceleration | Stable and efficient cruising | Fast throttle response | Refined and powerful |
| Efficiency | Excellent balance | Best endurance‑focused option | Higher power consumption | Balanced premium performance |
| Prop Recommendation | Lightweight 3" props | Efficient low‑pitch props | Racing/high‑response props | Freestyle/racing props |
| Suitable Pilot | Wants one motor for different builds | Prioritizes range and flight time | Wants aggressive racing feel | Wants premium motor performance |
Final Recommendation
The NIN 1404 V2 is a strong choice for pilots who want large‑motor performance in a lightweight FPV platform.
Compared with smaller micro motors, it delivers better torque and control. Compared with larger motors, it keeps the lightweight advantage that makes Toothpick and sub‑250g builds enjoyable.
For most pilots, 3750KV is the recommended all‑around option, offering the best balance between power, efficiency, and flight time. Choose 2750KV for long‑range exploration or 4850KV for maximum freestyle performance.
A correctly matched setup is the key to unlocking the full potential of the NIN 1404 V2 — this small motor can deliver a surprisingly powerful FPV experience when paired with the right propeller, battery, and frame.
