Flywoo GOKU F722 Pro Mini V2 45A 32Bit 128K 20X20 Stack Plug&Play O4 / O4 Pro
About Flywoo GOKU F722 Pro Mini V2 45A Stack:
The FLYWOO F722 PRO Mini V2 is a 20mm flight controller with a high-performance STM32 F722, supporting 8 motor outputs and dual 4-in-1 ESC sockets. Its user-friendly socket design simplifies connections, installation, and maintenance, while retaining solder pads for flexible setups. Plug-and-play support for DJI O3 Air Unit enables effortless integration with DJI digital systems.
Check out our 45A Stack, all FC ESC Stack Collection and the rest of our Flywoo Products!
Bundle and save up to $4.37 on gear — upgrade your setup for less.
MEPS SZ2207 V2 FPV Motor – Smooth Linear Power & Stable Thrust | 1750KV/1950KV/2750KV for 5'' Racing Drones
Options (10)
1750KV / Fluorescent Green
Sold Out
1750KV / Cyan
1950KV / Fluorescent Green
1950KV / Cyan
2750KV / Fluorescent Green
1750KV*4pcs / Fluorescent Green
Sold Out
1750KV*4pcs / Cyan
1950KV*4pcs / Fluorescent Green
1950KV*4pcs / Cyan
2750KV*4pcs / Fluorescent Green
1750KV / Fluorescent Green
$12.13
Save $0.77
MEPS Drone Cotton T-Shirt Fly in Style FPV Pilot Streetwear Apparel
Options (6)
Tie_Dye Gray/L
Tie_Dye Gray/XL
Tie_Dye Gray/XXL
Pearl White/L
Pearl White/XL
Pearl White/XXL
Tie_Dye Gray/L
$32.39
Save $3.60
In Stock
Expected ship within 5 days after order.
Free Shipping Over $79 | Save on Orders $79+
24-Month Warranty | 2 Years Full Protection
30-Day Returns From Shipment | 7-Day No-Reason Returns
24h Support Response | 24h Fast Support Guarantee
Top highlights
Ultra-Fast Processor: STM32F722 processor at 216MHz delivers lightning-fast response for smooth, high-performance flight.
Precision Flight Control: ICM42688 gyroscope ensures superior stability and precise maneuvering.
Modular & Easy Installation: Snap-lock sockets allow plug-and-play setup without soldering, with reserved pads for future upgrades.
Reliable Power & Motor Support: Onboard 10V/2A and 5V/2A BECs provide stable current, supporting 8 motors and dual 4-in-1 ESCs.
Durable & Data-Ready: Gold-plated PCB resists heat and high current, with a 16MB black box for comprehensive flight data.
Payment | Every order you place with us is safe & secure
Share
Powerful Plug-and-Play FPV Stack
The new generation F722 PRO Mini V2 flight controller from FLYWOO not only offers a standard 20mm size, high-performance STM32 F722 main control, but it also supports 8 motor outputs and reserves dual 4-in-1 ESC sockets.
It features a user-friendly socket design for all ports, which significantly simplifies the process of connecting devices, thereby enhancing installation efficiency and making maintenance and fault inspection more convenient. This design effectively lowers the threshold for building drones. Moreover, all solder pads are retained, providing customers with the flexibility to choose their preferred method of device connection. Furthermore, it includes a plug-and-play feature, specifically designed for the DJI O3 Air Unit, which streamlines the integration process for pilots looking to utilize DJI's advanced digital transmission system with their builds.
High-Speed DShot1200 ESC with 128kHz Refresh
Supports DShot1200 and 128kHz refresh rate for ultra-fast response and strong anti-interference. Compatible with PWM, Oneshot, and other throttle signals, ensuring smooth and precise motor control.
Enhacnced Efficiency and Performance ESC
Equipped with a high-performance AT32 chip, imported MOSFETs, and ceramic capacitors, the GOKU G45M ESC delivers efficient, stable power and smooth operation. Supports bi-directional DShot and data telemetry for precise motor control and real-time feedback.
Highlights
1. High-performance processor: Equipped with the STM32F722 high-performance processor with a processing speed of up to 216MHz for faster response.
2. Precision gyroscope: Features the ICM42688 gyroscope for improved control precision and enhanced flight stability.
3. Modular installation: Utilizes snap-lock sockets for plug-and-play functionality without the need for soldering, enabling modular installation, and includes reserved solder pads.
4. Large-capacity black box: Includes a 16MB large-capacity black box to ensure sufficient storage of flight data for later analysis.
5. Stable current output: Onboard 10V/2A and 5V/2A BEC to provide stable current output for VTX and various peripherals.
6. Multiple motor outputs: Supports 8 motor outputs and reserves dual 4-in-1 ESC sockets for simplified connections.
7. Durable design: Utilizes immersion gold PCB manufacturing process to ensure high-temperature and high-current resistance, guaranteeing stable operation.
Buying Guide: Is Flywoo GOKU F722 Pro Mini V2 Stack for Your FPV Build?
MEPSKING Review: A Balanced 20x20 F7 Stack Built for Smooth Freestyle Performance
After hands-on testing and build evaluation, we found that the Flywoo GOKU F722 Pro Mini V2 stands out from many compact FPV stacks by focusing on what pilots actually feel in the air — precise control, smooth response, efficient power delivery, and a clean building experience.
Unlike some mini stacks that simply increase current capacity, the flywoo goku f722 pro mini v2 is designed around overall flight balance. The combination of the STM32 F722 processor, ICM42688 gyro, AM32 32Bit ESC, and optimized power system provides a more refined control experience, especially during freestyle maneuvers where response consistency matters more than raw output.
During real flight testing, the stack showed excellent stability during fast direction changes, rolls, flips, and power loops. The drone feels more locked-in, with smoother stick input and predictable throttle response, allowing pilots to focus on flying rather than fighting the quad.
Compared with many budget-oriented stacks, the GOKU F722 Pro Mini V2 provides better tuning flexibility and a more premium flight feel. The additional processing capability, larger Blackbox storage, and reliable sensor performance help achieve smoother PID tuning and more consistent performance across different builds.
This is the setup where the stack shows its best balance.
The combination delivers:
✓ Enough power for modern 6S freestyle ✓ Smooth throttle control ✓ Lightweight handling ✓ Better response during tricks
Ideal for:
● Freestyle training
● Power loops
● Split-S
● Flow flying
● Daily FPV sessions
Who Should Buy Flywoo GOKU F722 Pro Mini V2?
The Flywoo GOKU F722 Pro Mini V2 is a strong choice for pilots who want a stack that feels balanced in real flight.
Choose this stack if you prefer:
✓ Smooth freestyle control ✓ Lightweight builds ✓ Easier handling ✓ Efficient 6S performance ✓ A versatile setup for different FPV styles
It is especially recommended for:
● First custom FPV builds
● Intermediate freestyle pilots
● Lightweight 5-inch pilots
● Pilots who prefer control and precision over maximum power
For most freestyle users, pairing it with SZ2207 1750-1950KV motors + SZ5145 props + 6S1300mAh battery creates the best balance between speed, control, and flight enjoyment.
Great little 20x20 stack for a clean 5 inch build. The F722 FC feels fast, ESC response is smooth, and the quad flies locked in.
Option：F722 Pro Mini V2 45A 32Bit 128K 20X20 Stack
s***********r
Verified
Great looking stack, easy soldering + huge amount of uarts. 5/5
Option：F722 Pro Mini V2 45A 32Bit 128K 20X20 Stack
Replied by MEPSKING:Thanks for your review and image! Glad you’re happy with the stack—clean build and easy soldering. Happy flying! 🚀
F******c
Verified
Configuration facile et bon rendement.
Option：F722 Pro Mini V2 45A 32Bit 128K 20X20 Stack
N***********s
Verified
MEPSKING support helped me confirm the firmware target before flashing. Shipping was safe and the stack came with all the needed cables.
Option：F722 Pro Mini V2 45A 32Bit 128K 20X20 Stack
D**********r
Verified
Motor control feels really smooth with AM32. Gyro is clean and the stack reacts fast. Nice choice for a lightweight freestyle build.
Option：F722 Pro Mini V2 45A 32Bit 128K 20X20 Stack
R***n
Verified
45A rating feels very honest, no issues on 6S. A must-have for a clean 20x20 build.
Option：F722 Pro Mini V2 45A 32Bit 128K 20X20 Stack
T**********r
Verified
45A rating feels honest. I ran it on 6S freestyle packs and had no desync or overheating. Power delivery is clean.
Option：F722 Pro Mini V2 45A 32Bit 128K 20X20 Stack
J**********r
Verified
Used it with DJI O4 and ELRS. Plug layout made wiring pretty simple, just double check the UART settings in Betaflight. Everything worked after setup.
Option：F722 Pro Mini V2 45A 32Bit 128K 20X20 Stack
1
2
FAQFeel free to ask us any questions
Q: What is the Flywoo GOKU F722 Pro Mini V2 45A stack designed for?
A: The Flywoo GOKU F722 Pro Mini V2 45A 20×20 stack is designed for 5-inch freestyle and lightweight FPV racing drones with DJI O4 / O4 Pro plug-and-play support.
Q: Is this stack good for 5-inch freestyle drones?
A: Yes — the 45A AM32 ESC and F722 FC provide strong power delivery and smooth control for aggressive freestyle flying.
Q: Does it support DJI O4 and O4 Pro plug-and-play?
A: Yes — it supports DJI O4 / O4 Pro plug-and-play integration for fast digital FPV setup with minimal soldering.
Q: Is the Flywoo GOKU stack beginner friendly?
A: Yes — plug-and-play connectors and pre-installed wiring reduce complexity, making it easier for beginners building digital FPV drones.
Q: Can it handle 6S LiPo batteries?
A: Yes — it supports 2–6S LiPo input, making it suitable for both mid-power and high-performance FPV builds.
