About T-HOBBY V70A SE 8S ESC+F7 SE 8S FC 4in1 FPV Stack:
The T-Hobby V70A SE 8S ESC + F7 SE 8S FC 4in1 FPV Stack is built for pilots who demand high performance and stability in extreme conditions. Supporting up to 8S input, it delivers powerful thrust and precise control for advanced freestyle and cinematic builds. With an optimized multi-layer PCB, upgraded 70A continuous current output, and a third-generation BEC for cleaner signal noise, this stack ensures efficient, smooth, and reliable flight performance. The full plug-in connection design also makes installation and maintenance faster and more convenient, offering both power and practicality in one compact system. Check out our 8S FPV Stacks, all Flight Controllers Collection and the rest of our T-HOBBY Products!
Payment | Every order you place with us is safe & secure
Share
Copy
Description
FAQ
Optimized Multi-Layer PCB
Designed for efficient power delivery with reduced current limitations, supporting stable 70A continuous output for smooth and reliable performance.
Full Plug-In Design
Uses the Betaflight-standard plug connection between FC and ESC for easier installation, cleaner wiring, and improved reliability.
Upgraded 3rd-Gen BEC
Reduces ripple voltage by 50% compared to the previous generation, ensuring cleaner signals and smoother gyro performance.
Buying Guide: T-HOBBY V70A SE 8S FPV Stack
Is T-HOBBY V70A SE Stack Worth Buying?
The T-HOBBY V70A SE 8S FPV Stack is a high-performance power system designed for pilots who need more capability than traditional 6S FPV stacks. Combining the V70A 4-in-1 ESC with the F7 SE flight controller, this stack delivers higher voltage support, stronger current handling, and advanced flight control features for modern FPV builds.
Compared with common 45A or 60A stacks, the V70A SE provides a significant upgrade with 70A continuous current, 8S battery compatibility, AM32 ESC firmware, and a powerful STM32F722 flight controller. It gives pilots more flexibility when building aggressive freestyle drones, long-range platforms, cinematic FPV machines, and heavy-duty FPV systems.
The biggest advantage of this stack is its balance between performance and value. Instead of choosing an expensive high-end stack, pilots can get features usually found on premium hardware while keeping the build cost under control.
Application Scenarios
The T-HOBBY V70A SE 8S FPV Stack is designed for advanced FPV builds where higher power capability, voltage flexibility, and reliable performance are important.
Application
Recommended Setup
Why Choose V70A SE
5-Inch High Performance Freestyle Drone
6S LiPo battery + 2207/2306 motors + 5-inch propellers + Digital FPV system
Provides additional current margin during aggressive throttle punches, freestyle maneuvers, and high-speed flight.
Supports efficient long-range configurations with stable power delivery and enough capacity for extended flights.
Cinematic FPV Build
Large frame + HD camera + GPS + high-capacity battery
Provides extra power reserve for carrying additional equipment while maintaining smooth control.
Heavy Payload FPV Platform
Low KV high torque motors + 8S LiPo system
Higher voltage support helps reduce current demand while improving efficiency.
How to Choose Battery Voltage?
The T-HOBBY V70A SE supports 4S–8S LiPo batteries, but the correct voltage depends on your frame size, motor KV, propeller size, and flying purpose.
Battery
Recommended Application
4S
Lower power builds, easier tuning, and smaller FPV platforms.
6S
The best balance for 5–7 inch freestyle drones, long-range builds, and most advanced FPV applications.
8S
Maximum efficiency setups, heavy payload platforms, and high-power long-range FPV builds.
Choose 6S if:
● Building a 5–7 inch freestyle drone
● Want balanced power output and flight time
● Using common FPV motors and components
Choose 8S if:
● Building long-range FPV platforms
● Carrying heavier payloads
● Using low KV high torque motors
For most pilots, 6S remains the easiest and most practical choice. Experienced builders who need maximum efficiency and power reserve can take advantage of the 8S capability.
T-HOBBY V70A SE vs Flywoo GOKU F722 Pro V2 vs Axisflying Argus PRO: Which Stack Should You Choose?
When choosing a high-performance FPV stack, current capability, voltage support, flight controller performance, ESC firmware, and intended application are all important factors.
The T-HOBBY V70A SE focuses on high-power FPV applications with 8S support and a 70A ESC, while the Flywoo GOKU F722 Pro V2 and Axisflying Argus PRO are designed for versatile 5-inch and 6-inch FPV builds.
Specification
T-HOBBY V70A SE 8S Stack
Flywoo GOKU F722 Pro V2 55A Stack
Axisflying Argus PRO Stack
Best For
High-power freestyle / 8S builds / cinelifter
Freestyle / Racing / DJI O3-O4 builds
Freestyle / Cinematic / Easy installation
Mounting Pattern
30.5×30.5mm
30.5×30.5mm
30.5×30.5mm
Flight Controller MCU
STM32F722
STM32F722
STM32F722
Gyroscope
ICM42688P
ICM42688P
ICM42688P
ESC Current Rating
70A Continuous
55A Continuous
55A / 65A Continuous
ESC Firmware
AM32
BLHeli_32
BLHeli_32
Input Voltage
4S–8S LiPo
3S–6S LiPo
3S–6S LiPo
PWM Frequency
Up to 128KHz
Up to 128KHz
Up to 128KHz
BEC Output
5V / 10V
5V / 9V
5V / 9V
DJI O3/O4 Support
Compatible
Plug & Play
Plug & Play
Blackbox
128MB
128MB
Yes
Current Sensor
Yes
Yes
Yes
GPS Support
Yes
Yes
Yes
Recommended Frame Size
5" / 6" / 7" / Cinelifter
5" / 6"
5" / 6"
Main Advantage
Higher power capability and 8S support
Mature 6S freestyle solution
Easy setup and integrated design
Which Stack Should You Choose?
The best FPV stack depends on your build requirements, flying style, and power system. Each stack has a different design focus.
Choose T-HOBBY V70A SE if you:
● Need higher current capability for powerful FPV builds
● Want 8S LiPo support for long-range or heavy-duty platforms
● Build 7-inch drones, cinelifters, or high-power freestyle quads
● Prefer AM32 ESC firmware and flexible high-voltage configuration
Choose Flywoo GOKU F722 Pro V2 if you:
● Build standard 5-inch freestyle or racing drones
● Need a mature and easy-to-use stack solution
● Use DJI O3/O4 digital FPV systems
Choose Axisflying Argus PRO if you:
● Want a convenient plug-and-play FPV stack
● Build freestyle or cinematic FPV platforms
● Prefer simple installation and reliable everyday performance
Specification
Flight Controller – Velox F7 SE 8S
● MCU: STM32F722
● Gyroscope: ICM-42688P
● Firmware: Betaflight
● OSD: AT7456E (HD Supported)
● BEC Output: 5V / 3A & 12V / 3A
● UARTs: 5
● Wireless Connectivity: Bluetooth
● Input Voltage: 4–8S LiPo
● Mounting Pattern: 30.5 × 30.5 mm (M4)
● Dimensions: 38 × 38 × 7 mm
● Weight: 8 g
ESC – Velox V70A SE 8S (4-in-1)
● Continuous Current: 70A
● Peak Current: 75A
● Input Voltage: 4–8S LiPo
● ESC Firmware: AM32
● ESC MCU: AT32F421
● Power Layer Design: Optimized Multi-Layer PCB
● Blackbox Memory: 128MB
● USB Interface: USB Type-C
● Mounting Pattern: 30.5 × 30.5 mm
● Dimensions: 44.4 × 41 × 6 mm
● Weight: 12.3 g
Parameters
FC Model
Velox F7 SE 8S
ESC Model
Velox V70A SE 8S 4IN1
FC Size
38*38*7mm
ESC Size
44.4*41*6mm
FC Weight
8g
ESC Weight
12.3g
FC Packed Size
65*65*20mm
Packed Size
90*60*35mm
FC Packed Weight
25g
Packed Weight
50g
Specifications
Input Voltage
4–8S
Con Current
70A
Firmware
BETAFLIGHT
ESC MCU
AT32F421
MCU
STM32F722
ESC BEC
NONE
BEC
5V/3A&12V/3A
Galanometer Ratio
150
OSD
AT7456E&HD
Peak Current (5S)
75A
Wireless
BLUETOOTH
ESC Firmware
AM32
Mounting Hole
30.5*30.5mm/Φ4mm
ESC Galvanometer
SUPPORT
Unified Target
TMTR-TMOTORVELOXF7SE
Black Box
128MB
Gyroscope
ICM-42688P
USB
TYPE-C
Uarts
5
Recommended Combo
Motor
V3120 KV700
Frame Type
X4
Prop
C10.5*9*3
Battery Voltage
8S
ESC
Velox V70A SE 8S 4IN1
Recommended Takeoff Weight
Within 9kg
FC
Velox F7 SE 8S
Maximum Takeoff Weight
15kg
Test Data 1. 5500mAh 8S LiPo (1.3kg), payload 2kg, takeoff weight 5.9kg, flight time 10min. 2. 5500mAh 8S LiPo (1.3kg), payload 4kg, takeoff weight 7.9kg, flight time 6min.
Note: Recommended ESC settings: 30% startup power, AUTO timing, PWM Frequency: 16-BY RPM, for optimal efficiency and flight (improper settings may cause decay).
Please verify all items are included in the package before use. Contact our online support promptly if anything is missing. E-mail: online@mepsking.com
I just had to leave a review for MEPSKING this was honestly one of the best customer service experiences I’ve had.
From the start, delivery was perfect and right on time. What really stood out was how incredibly responsive and helpful they were when I emailed about changing my order they handled it quickly and without any hassle.
And then… they surprised me with FOUR extra brand new motors. That genuinely blew me away.
It’s rare to see this level of service, generosity, and professionalism these days. Huge thanks to the MEPSKING team — you absolutely deserve all the positive reviews coming your way!
KV：V70A SE 8S ESC+F7 SE 8S FC
Replied by MEPSKING:Thanks so much for your amazing feedback! We’re thrilled you had such a great experience with MEPSKING. Glad our support and the surprise motors made your day. We truly appreciate your trust and support. Enjoy and Happy flying!
J*****z
Verified
Soporta bien la carga. Envío rápido sin retrasos ♡♡♡
KV：V70A SE 8S ESC+F7 SE 8S FC
B***********t
Verified
Running on 8S, power delivery is smooth and consistent even under aggressive flying. Build quality looks solid.
KV：V70A SE 8S ESC+F7 SE 8S FC
Additional reviews after 19
days
After more flights, still performing strong. No overheating or instability noticed.
z********7
perfetta
KV：V70A SE 8S ESC+F7 SE 8S FC
Purchased 2 times
Replied by MEPSKING:Grazie! Siamo felici che tutto funzioni perfettamente. Buoni voli con MEPSKING! 🚀
l**********a
Verified
Excellent stack! Ive had multiple drones with t-hobby stacks and they have never failed me. Very good quality, reliable and easy to use. Very good price for this product at Mepsking. Recommend.
KV：V70A SE 8S ESC+F7 SE 8S FC
Replied by MEPSKING:Thank you for your support! We’re glad the stacks have been reliable for you. Quality and value are what we aim for at Mepsking. Appreciate the recommendation—Happy flying! 🚀
B*********t
Verified
Strong and reliable setup. Perfect for high voltage builds and long range flights.
KV：V70A SE 8S ESC+F7 SE 8S FC
Purchased 3 times
Additional reviews after 6
days
After more long flights, still stable and performs like new.
Replied by MEPSKING:Thanks for your feedback! Glad it's working great on your build.
D**********s
Verified
Muy buen stack, potente y confiable para vuelos largos.
KV：V70A SE 8S ESC+F7 SE 8S FC
A********g
Verified
Runs very smooth even with aggressive throttle input. ESC response is very clean.
KV：V70A SE 8S ESC+F7 SE 8S FC
Purchased 2 times
1
2
3
FAQFeel free to ask us any questions
ASK A QUESTION
Q: What mounting pattern does this stack use?
A: It uses a standard 30.5×30.5mm mounting pattern, compatible with most FPV frames.
Q: What voltage does this stack support?
A: It supports 4–8S LiPo batteries, designed for high-voltage FPV builds.
Q: What is the ESC current rating?
A: 70A continuous current with higher burst capability for demanding setups.
Q: What flight controller is included?
A: It includes an F7 flight controller for fast processing and stable performance.
Q: What type of drones is it best for?
A: Ideal for 5–7 inch freestyle, racing, or long-range high-power builds.
