NewLumenier LUX HD Solderless AIO - G4 FC + 35A AM32 3-6S ESC
Built to LastBest Value
Extra 5% Off
Collect
$116.99
$129.99
-10%
5.0|100+Sold
Options (1)
G4 FC + 35A AM32 ESC
Quantity
In Stock
Expected ship within 3 days after order.
Estimated Transit Time: 15-20 Days.
Free Shipping Over $99 | Save on Orders $99+
24-Month Warranty | 2 Years Full Protection
15-Day Easy Returns | 15-Day No-Risk Return
24h Support Response | 24h Fast Support Guarantee
Dual-Processor Power: G4 FC + Four F4 processors dedicated to the 35A AM32 ESC.
High-Current ESC: 3-6S LiPo input for demanding racing and freestyle setups.
Solderless: Pre-installed motor plugs and an XT30 connector for easy installation.
DJI O3 Dedicated Design: Seamless integration with DJI O3 Air Unit systems.
Compact & Lightweight: Standard 25x25mm mounting pattern, weighing under 13g.
Payment | Every order you place with us is safe & secure
Share
Copy
Description
FAQ
About this Product
The Lumenier LUX HD AIO G4 Flight Controller + ESC is a powerful solderless AIO ready to power the DJI O3 in a simple configuration. The LUX HD AIO G4 builds on all the best features of its predecessors and further improves on hardware components and layout, and is now dedicated to a design for the DJI systems. The FC uses a G4 processor and top-of-the-line hardware from the 35A AM32 3-6S ESC powered by four F4 processors! This LUX HD AIO G4 comes in a standard 25x25 mounting pattern, weighing just under 13g. The solderless design has plugs installed for your motors, XT30 connection, and more... just plug in and fly. Unleash the capabilities of your FPV Racing Quadcopter with the Lumenier LUX HD AIO G4 Flight Controller!
Note: This AIO works with both the DJI O3 and other Digital FPV Systems. Plug-n-play, no soldering required. This AIO is also Analog compatible.
Features
Solderless Version (includes motor plugs + pre-soldered XT30 power cable)
Low resistance Mosfet with a Metal case, up to 6s 35A supported
Analog current sensor3~6S Lipo (12.6~25.2V) Input
35A AM32 ESC (F4 processors)
16M Flash Memory Blackbox
25x25mm Mounting Pattern
G473 Flight Controller
OSD (Analog / Digital)
ICM42688 Gyro
DJI Ready
Specifications
MCU: STM32G473 / 170Mhz / 512KB Flash
BEC: 2x BEC, 5V and 10V, 2.5A each
VBAT Input: 8-32V, 3-6S Lipo
Blackbox: 16MB (128M Bit)
MOSFET: Low resistance
Amperage: 35A up to 6S
Current sensor: Analog
Dimensions: 38x38mm
DJI Digital Port: Yes
ESC MCU: F4 AM32
Gyro: ICM42688
PMW Output: 4
Weight: 12.83g
LED: WS2812b
FC MCU: G473
Beepers: Yes
OSD: Yes
12C: 1
FAQFeel free to ask us any questions
ASK A QUESTION
Q: Is the solderless design reliable enough for hard crashes and everyday use?
A: Yes. The pre-installed plugs and XT30 connector are securely mounted and strain-relieved, designed to withstand repeated impacts. Removing solder joints actually eliminates common failure points like cold solder joints or wire fatigue, making this AIO both easier to build and more durable for long-term flying.
