MEPS NEONCORE F405 60A 4-in-1 FPV-Stack – 30,5 x 30,5 mm

Step Up to Real 60A Performance

The MEPS Hypercore stack provides a ferocious, heavy-duty all-in-one flight and power system. It supports a massive 3S–8S LiPo input with a true 60A continuous and 80A peak output, effortlessly driving high-power motors. Built with premium MOSFETs and thick internal copper layers, it delivers an incredibly smooth, stable, and desync-free performance even under aggressive full-throttle punches and demanding freestyle flights.

Locked-in Precision for High-Speed Freestyle

Powered by a high-performance STM32F405 MCU paired with the ultra-clear ICM42688P IMU, this stack delivers laser-sharp gyro telemetry and lightning-fast processing speeds. Its heavy-duty core ensures zero latency, rock-solid filtering, and locked-in control during aggressive freestyle maneuvers and tight cinematic flow.

Heavy-Duty Protection & Thermal Stability

Stop worrying about destroying delicate components during high-impact drops. The MEPS Hypercore features a full-wrap CNC aluminum alloy armor that acts as a bulletproof vest against direct structural impacts and flying debris.

Beyond pure physical defense, this heavy-duty shell serves as a high-efficiency cooling pad. By keeping critical MOSFETs ice-cold under continuous heavy loads, it maintains rock-solid voltage/current telemetry accuracy and completely eliminates motor desyncs. Power through demanding flights—your power loop is fully guarded.

Factory Pre-Waterproofed: Shield Against the Elements

Skip the messy chore of brushing on your own silicone protection. The MEPS Hypercore ESC comes completely factory pre-treated with premium industrial-grade waterproofing. This full-coverage insulative barrier shields your sensitive electronic components against morning dew, wet grass, fog, and unexpected splashes. Keep your focus entirely on the sticks—damp environments won't compromise your flight.

Stop Tweakng, Start Ripping

Forget the frustration of endless Betaflight slider adjustments and blackbox log analysis. The MEPS Hypercore arrives with a mature, masterfully optimized stock PID profile right out of the box.

Backed by thousands of hours of real-world testing, this stack is engineered to provide a smooth, responsive, and "locked-in" authority for 5-inch rigs. Experience lightning-fast stick response and flawless filtering without ever picking up a USB cable. Just power on and dominate the air instantly.

Your Build, Your Choice

Whether you are a beginner looking for a hassle-free setup or a seasoned pilot who demands a custom wired layout, this stack adapts to your building style.

Solder-Free Plug & Play: The stack comes with a built-in DJI digital air unit and HD FPV interface, along with direct receiver plug support, enabling a solder-free setup for faster assembly and cleaner wiring.

Anti-Bridge Traditional Pads: Prefer traditional welding? We've got you covered. The reserved motor and power pads feature oversized spacing and physical isolation, making soldering effortless and completely eliminating the risk of accidental solder bridges.

F405 Flight Controller Wiring Diagram

⚠️Installation & Setup Guide (Must-Read):

1. Verify Wiring Pinouts Strictly： The ESC and O3/O4 Air Unit cables on this stack feature a redundant multi-pin design, which differs from standard standard pinouts. Always cross-check the wire sequence (pin-to-pin) before plugging them in. DO NOT plug them in blindly, or you risk burning out your Air Unit or Flight Controller.

2. Add Stack Spacers for Clearance: Due to the thick metal heatsink, the FC bottom components may physically interfere with the ESC armor. You MUST install the included spacers or nylon nuts between the ESC and FC to ensure enough clearance and vibration dampening space.

3. Configure Refresh Rate (Prevent Crashing): The F405 MCU has limited processing power. If you enable Bidirectional DSHOT (RPM Filtering), please set your PID loop/gyro refresh rate to 8K/4K or 4K/4K. DO NOT run at dual 8K, as overloading the CPU can cause mid-air freezes or random reboots.

4. Motor Direction Adjustment: If you cannot change the motor direction in Betaflight Configurator after enabling Bidirectional DSHOT, go to the CLI tab, type: set dshot_bitbang = AUTO and press Enter, then type save. Alternatively, temporarily disable Bidirectional DSHOT, change the motor direction, and re-enable it.

Specifications

F405 Flight Controller

NEON 60A ESC

Size Chart

Recommendation
